Equinox Analytical and Semi-Micro Balances-EAB 124e
Featuring a high-resolution colour touch screen, Equinox analytical balances provide intuitive operation and readily accessible functions. Equinox delivers exceptionally precise results for labs, science education and production facilities.
Applications
-
-
-
-
-
-
-
-
-
-
-
Features
-
-
-
-
-
-
-
-
-
-
-
Equinox analytical balances deliver remarkable precision to labs that perform highly detailed testing. The Equinox is ideal for research and quality assurance facilities; science education; precision counting; and production and manufacturing applications needing exceptionally precise results. Eight analytical models offer capacities from 120g to 510g and 0.1mg readability. A colour touch screen display provides intuitive operation, with icon-driven menus and readily accessible applications and functions. The five-inch screen is generously sized, offering 800 X 480 pixel resolution for excellent visibility.
Features and Benefits
- Large, responsive 5’’ 800x480 pixel touch-screen display
- Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
- Large, grade 304 stainless steel pan allows easy cleaning
- RS-232 interface provides speedy connection to computers and printers
- USB host for memory card
- AC adapter included
- Built-in memory for storing products and settings
- External calibration allows for verification and adjustment with weights
- Selectable digital filtering helps minimise effects of vibration and disturbances
- Security password control prevents unauthorised access
- Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
- Preset tare function speeds the process of repetitive weighing
- Parts counting with freely selectable sample sizes
- Multilingual display allows use in many different countries
- Memory accumulation totals results
- Checkweighing with audible alarm
- Security slot for optional lock and cable to help prevent theft
- A 5-year warranty means quality assured for years of use.
Technical specification
Model
EAB 124e
UPC: 840886104580
Metrology
Capacity
- 120g
- 120g
Readability
- 0.0001g
- 0.0001g
Repeatability
- 0.0001g
- 0.0001g
Linearity
- 0.0003g
- 0.0003g
Min Weight USP
- 200
- 200
General Specifications
Pan size
- 80mm ø
- 80mm ø
Weighing Units
- ct, custom unit, dwt, g, GN, lb, mg, mm, oz, ozt, T, tl.H, tl.S, tl.T
- ct, custom unit, dwt, g, GN, lb, mg, mm, oz, ozt, T, tl.H, tl.S, tl.T
Stabilisation Time
- 4
- 4
Interface
- RS-232/USB
- RS-232/USB
Calibration
- External calibration
- External calibration
Display
- Touchscreen with 13mm high digits
- Touchscreen with 13mm high digits
Power
Power Supply
- 24VDC 1A Adapter
- 24VDC 1A Adapter
Operating Conditions
Operating Temperature
- 10° to 30°C / 50° to 86°F
- 10° to 30°C / 50° to 86°F
Product Information
Construction
- ABS plastic
- ABS plastic
Net Weight
- 6.5kg
- 6.5kg
Dimensions
Draft Shield Type
- Chamber
- Chamber
Overall dims
- 224x374x338mm
- 224x374x338mm
Downloads
Accessories
Here is a list of our available related products and suitable accessories:
