Intuitive Operation, Dependability,
Performance and Value since 1972

Nimbus® Analytical Balances-NBL 214E

Capacity
210g
Readability
0.0001g
Pan Size
90mm ø
View alternative models
Designed with scientists in mind, the Nimbus series of balances offers a range of models that deliver readabilities of 0.1mg. Creative and innovative design enables a smaller footprint, so the Nimbus occupies less space but retains the highest level of performance. Designed to be intuitive, the navigation buttons are large and colour-coded, helping users operate the balance and perform functions with minimal training. Data collection and transmission is optimised with the Nimbus's USB and RS-232 interfaces.
Warranty 5 yearsWarranty 5 years

Features

Backlit DisplayBacklit Display
RS-232RS-232
USBUSB
External CalibrationExternal Calibration
GLPGLP
Security LockSecurity Lock
Toggle icon descriptions
Innovative design enables a compact footprint, so it occupies minimal space but retains a high level of performance. The Nimbus base is formed from a single piece of extruded aluminum, a material that provides superior temperature regulation. The single-piece construction offers greater stability, producing highly repeatable results. The weighing sensor in the Nimbus is crafted from a single block, and contains fewer parts than a traditional force motor balance. This optimized internal mechanism is fabricated using hardened materials, helping the Nimbus tolerate rigorous laboratory use. Efficiency in the mechanics, plus improved processing power of the electronics, leads to excellent performance.

Features and Benefits

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Lockdown device to secure balance
  • AC adapter included
  • External calibration allows for verification and adjustment with weights
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering for animal/dynamic weighing enables consistent results for moving subjects
  • Zero-tracking feature ensures display returns to zero reading
  • Multilingual display allows use in many different countries
  • A 5-year warranty means quality assured for years of use.

Technical specification

Model

NBL 214e

UPC: 819309018636

Metrology

  • Capacity
    • 210g
  • Readability
    • 0.0001g
  • Repeatability
    • 0.0001g
  • Linearity
    • 0.0003g
  • Min Weight USP
    • 0.01g

General Specifications

  • Pan size
    • 90mm ø
  • Weighing Units
    • ct, custom unit, dwt, g, GN, mg, N, oz, ozt
  • Stabilisation Time
    • 4
  • Interface
    • RS-232/USB
  • Calibration
    • External calibration
  • Display
    • Backlit LCD with 20mm high digits

Power

  • Power Supply
    • 18VDC 830mA adapter

Operating Conditions

  • Operating Temperature
    • 15° to 35°C / 59° to 95°F

Product Information

  • Construction
    • Extruded aluminum base with a die-cast aluminum case
  • Net Weight
    • 5.25kg

Dimensions

  • Draft Shield Type
    • Chamber
